| Part Number | Dimension (mm) | ||
| Fw | D | C | |
| NCS1012 | 15.875 | 28.575 | 19.05 |
| NCS1016 | 15.875 | 28.575 | 25.40 |
| NCS1212 | 19.050 | 31.750 | 19.05 |
| NCS1216 | 19.050 | 31.750 | 25.40 |
| NCS1412 | 22.225 | 34.925 | 19.05 |
| NCS1416 | 22.225 | 34.925 | 25.40 |
| NCS1612 | 25.400 | 38.100 | 19.05 |
| NCS1616 | 25.400 | 38.100 | 25.40 |
| NCS1816 | 28.575 | 41.275 | 25.40 |
| NCS1820 | 28.575 | 41.275 | 31.75 |
| NCS2016 | 31.750 | 44.450 | 25.40 |
| NCS2020 | 31.750 | 44.450 | 31.75 |
| NCS2216 | 34.925 | 47.625 | 25.40 |
| NCS2220 | 34.925 | 47.625 | 31.75 |
| NCS2416 | 38.100 | 52.388 | 25.40 |
| NCS2420 | 38.100 | 52.388 | 31.75 |
| NCS2616 | 41.275 | 55.563 | 25.40 |
| NCS2620 | 41.275 | 55.563 | 31.75 |
| NCS2816 | 44.450 | 58.738 | 25.40 |
| NCS2820 | 44.450 | 58.738 | 31.75 |
| NCS3016 | 47.625 | 61.913 | 25.40 |
| NCS3020 | 47.625 | 61.913 | 31.75 |
| NCS3216 | 50.800 | 65.088 | 25.40 |
| NCS3220 | 50.800 | 65.088 | 31.75 |
| NCS3624 | 57.150 | 76.200 | 38.10 |
| NCS4024 | 63.500 | 82.550 | 38.10 |
| NCS4424 | 69.850 | 88.900 | 38.10 |
| NCS4824 | 76.200 | 95.250 | 38.10 |
| NCS5228 | 82.550 | 107.950 | 44.45 |
| NCS5632 | 88.900 | 114.300 | 50.80 |
| NCS6832 | 107.950 | 133.350 | 50.80 |
